Video-Eingangsnummer/-signal
HDMI 2.0 x 1
HDMI 1.3 x 3
3G-SDI x 1
Verbindung
Female HDMI type-A / 3G-SDI
Auflösungsbereich
HDMI Input 1: 720p~2160p 60fps, 1920x1200(RB)
HDMI Input 2~4 and 3G-SDI: 720p~1080p 60fps
IP Quelle / USB Kamera
Lumens IP PTZ / Box Camera
NDI High Bandwidth, NDI HX2, NDI HX3 Source
RTSP Source (HEVC / H.264)
USB Camera (MJPEG 1080p 30fps)
Video-Komprimierung
HEVC / H.264 / AVC 4:2:0 8bit color
Encoding Profile: High, Main, Baseline
Anzahl der Videoausgänge / Signal
HDMI x2
HDMI Loop-through x1
UVC (up to 1080p) x1
Skalierte Auflösung
2160p / 1080p
Bildrate
60 / 50 / 30/ 25 fps
Monitor
2 inch color LCD screen
Interner Speicher
4TB HDD
Externer Speicher
USB Storage
Dateityp
H.264 / HEVC in an MP4 container, JPEG
Auflösung
2160p / 1080p / 720p / 480p / 360p
Audio-Eingangsnummer/-signal
Line In (Stereo Unbalanced Audio, 3.5mm Phone Jack) x2
Combo (XLR/TRS, Balanced Audio, Line in/ Mic in,
Support +48V Phantom Power) x2
IP Audio Source (RTSP, NDI, 16K/44.1K/48K)
Support UAC
Audioverarbeitung / Komprimierung
AAC-LC
Anzahl der Audioausgänge / Signal
XLR, Balanced Audio, Line Out x2
stereo, Unbalanced 3.5mm Phone Jack x2
stereo, Digital De-embedded Audio from HDMI x2
USB (UAC) x1
USB
USB 2.0 Type A x2
USB 3.0 Type A x2
Support USB Storage, USB Camera, USB Mic.
USB Mouse, Keyboard, HID Touch Display
USB 3.0 Type-B (UVC/UAC) x1
Serielle Steuerung
RS-232 In/ RS-232 Out
Ethernet Host-Anschluss
female RJ-45 x2
10 / 100 / 1000 Base-T High/Full Duplex
Streaming-Protokoll
Pull: RTSP / NDI High Bandwidth
Push: RTMP / RTMPS / RTP / SRT
TCP, UDP, HTTP
DHCP Client
Unterstützung von IP Quellen
Lumens IP Camera, RTSP, NDI
Szenen-Wechsel
Yes (Preset for Layout, Background, and Overlay)
Umschalter "Hintergrund"
Yes
Overlay
Yes (PNG Overlay)
Dateisicherung
FTP / SFTP / NAS(CIFS / SMB, NFS)/ WebDAV /
USB Storage
Content-Management-Systeme
Panopto / OpenCast / Kaltura
Stromversorgung
DC In , 19V / 6.8A
Abmessungen: (BxHxT)
Standard 1.5U rack
16.6" x 2.58" x 8.48" (422 x 65.5 x 215.5 mm)
Gewicht
7.72 lbs (3.5 Kg)
